Morningstar EcoPulse Solar Controller - Metered - SR-EC20M
Morningstar EcoPulse Solar Controller - Metered - SR-EC20M
Regular price
$331.00 AUD
Regular price
Sale price
$331.00 AUD
Taxes included.
Shipping calculated at checkout.
SKU:SR-EC20M
Quantity
Shipping Information:
Shipping costs may vary depending on the size, weight and destination of this product. For an exact shipping quote, please contact our team on 0484 945 845 before placing your order.
Shipping costs may vary depending on the size, weight and destination of this product. For an exact shipping quote, please contact our team on 0484 945 845 before placing your order.
Product Details
The EcoPulse is a pulse width modulation (PWM) solar charge controller within the Morningstar Essential Series™ which provides essential off-grid battery regulation functions. This controller is easy to use and was developed for residential and leisure consumer applications. Metered and non-metered versions of this product are available at 10, 20, and 30 amp charge ratings for 12 and 24 volt battery systems.
Additional information
| SKU | SR-EC10M, SR-EC20M, SR-EC30M |
|---|
Accessories
| Description | |
|---|---|
 |
Remote Temperature Sensor (RTS) |
Note: Specifications subject to change without notice
Features
- High Reliability – conformally coated circuit board and corrosion resistant terminals.
- Robust Thermal Design – extruded aluminum heatsink dissipates heat quickly without using cooling fans.
- Durable Casing – high strength polycarbonate case.
- LED Fault Indications – alert when short circuit, over current, high voltage, and other error conditions take place.
- Automatic Solar Based Lighting Control – field adjustable dusk ‘til dawn setting.
- Adjustable Charge Settings – seven presets and a custom setting can be set via DIP Switches or by the meter display buttons.
- Adjustable Load Control – load control can be adjusted via meter display.
- Optional Meter – multi-lingual interface with scroll buttons to adjust the settings and display metrics.
Specifications
| Morningstar EcoPulse 10amp w/-Meter | Morningstar EcoPulse 20amp w/-Meter | Morningstar EcoPulse 30amp w/-Meter | |
|---|---|---|---|
| SKU | SR-EC10M | SR-EC20M | SR-EC30M |
| Electrical | |||
| Nominal Battery Voltage | 12V or 24V auto-detect | 12V or 24V auto-detect | 12V or 24V auto-detect |
| Battery Voltage Range | 10-35V | 10-35V | 10-35V |
| Voltage Accuracy | <= 0.1% +/- 50mV | <= 0.1% +/- 50mV | <= 0.1% +/- 50mV |
| Maximum Battery Current | 10A, 20A or 30A | 10A, 20A or 30A | 10A, 20A or 30A |
| Maximum PV open-circuit voltage | 60V | 60V | 60V |
| Load Current Rating | 10A, 20A or 30A | 10A, 20A or 30A | 10A, 20A or 30A |
| Self-Consumption | <15mA; <20mA (meter) | <15mA; <20mA (meter) | <15mA; <20mA (meter) |
| LED Indications | (1) status, (3) Battery state of charge | (1) status, (3) Battery state of charge | (1) status, (3) Battery state of charge |
| Transient Surge Protection | 1500 Watts (solar, battery, load) | 1500 Watts (solar, battery, load) | 1500 Watts (solar, battery, load) |
| Environmental | |||
| Operating Temperature | -40°C to + 45°C | -40°C to + 45°C | -40°C to + 45°C |
| Storage Temperature | -40°C to + 80°C | -40°C to + 80°C | -40°C to + 80°C |
| Humidity | 100% non-condensing | 100% non-condensing | 100% non-condensing |
| Tropicalization | conformal coating, marine-rated terminals | conformal coating, marine-rated terminals | conformal coating, marine-rated terminals |
| Mechanical | |||
| Dimensions (W x L x D) | 15.3 x 10.5 x 5.5 cm 6.0 x 4.1 x 2.2 in |
15.3 x 10.5 x 5.5 cm 6.0 x 4.1 x 2.2 in |
15.3 x 10.5 x 5.5 cm 6.0 x 4.1 x 2.2 in |
| Weight | 0.4 kg / 1.0 lbs | 0.4 kg / 1.0 lbs | 0.4 kg / 1.0 lbs |
| Wire Size Range | Power Terminals: 2.5 – 16 mm2 / 14 – 6 AWG Battery/Temp. Sense: 0.25 – 1.0 mm2 / 24 – 16 AWG |
Power Terminals: 2.5 – 16 mm2 / 14 – 6 AWG Battery/Temp. Sense: 0.25 – 1.0 mm2 / 24 – 16 AWG |
Power Terminals: 2.5 – 16 mm2 / 14 – 6 AWG Battery/Temp. Sense: 0.25 – 1.0 mm2 / 24 – 16 AWG |
| Enclosure | IP20, Type 1 | IP20, Type 1 | IP20, Type 1 |
| Electronic Protections | |||
| Solar Input | overload, short-circuit, high voltage, reverse polarity, high temperature, nighttime reverse current | overload, short-circuit, high voltage, reverse polarity, high temperature, nighttime reverse current | overload, short-circuit, high voltage, reverse polarity, high temperature, nighttime reverse current |
| Load Output | overload, short-circuit, high temperature, reverse polarity | overload, short-circuit, high temperature, reverse polarity | overload, short-circuit, high temperature, reverse polarity |
| Battery | reverse polarity (no battery removal) | reverse polarity (no battery removal) | reverse polarity (no battery removal) |
| Battery Charging | |||
| 4-Stage charging | Bulk, Absorption, Float, Equalize | Bulk, Absorption, Float, Equalize | Bulk, Absorption, Float, Equalize |
| Temperature Compensation Coefficient | -30mV/°C/12volt | -30mV/°C/12volt | -30mV/°C/12volt |
| Set-points | Absorption, Float, Equalize, HVD | Absorption, Float, Equalize, HVD | Absorption, Float, Equalize, HVD |
| Load & Lighting Control | |||
| Low Voltage Disconnect, Low Voltage Reconnect Settings | 11.4 V / 12.6 V or Custom (x2 for 24 volt systems) | 11.4 V / 12.6 V or Custom (x2 for 24 volt systems) | 11.4 V / 12.6 V or Custom (x2 for 24 volt systems) |
| Lighting Settings | Dusk to Dawn | Dusk to Dawn | Dusk to Dawn |
| Certifications | |||
| CE, TUV Listed | IEC 62109 | IEC 62109 | IEC 62109 |
| Meter | |||
| Resolution | 128 x 64 pixels | 128 x 64 pixels | 128 x 64 pixels |
| Viewing Area | 5.0 cm x 2.5 cm | 5.0 cm x 2.5 cm | 5.0 cm x 2.5 cm |
| Interactive | Yes | Yes | Yes |
Note: Specifications subject to change without notice.
Manuals, Safety Information And Downloads
- EcoPulse Data Sheet (1.2mb)
- Operation Manual (4.5mb)
